>> Flexible Mono-crystalline Solar Panels from Jingyang (Kit with 12V Battery Charger included)

PRODUCT DETAILS:

1. ETFE 32-90 Solar Panel :

• Material: Monocrystalline silicon
• Max. Power (Pmax): 90W ± 5%
• Max. Power Voltage (Vmp): 18.50V
• Max. Power Current (Imp): 4.86A
• Open-Circuit Voltage (Voc): 23V
• Short-Circuit Current (Isc): 5.1A
• Nominal Operating Cell Temp. (NOCT): -45 to 80℃ / -49°F to 176°F
• Max. System Voltage: DC1000V
• Max. Series Fuse: 15A

Dimensions:

• 885mm (L) * 535mm (W) * 2.5mm (H)
• 34.84 inches (L) * 21.26 inches (W) * 0.09 inches (H)
  _{"AND THINNER THAN 2 PENNIES"}

Package Dimension:

• 900mm * 570mm * 40mm
• 35.43 inches * 22.44 inches * 1.57 inches
• Package Weight: 1.95kg

Standard Test Conditions: AM=1.5, Irradiance=1000W/m², Temp.=25℃

Warranty: 1 Year

Lifetime: 8-10 Years

Additional Information: Minor reduction in efficiency under partial load conditions at 25°C/ 77°F: achieves 95% (+/-5%) of STC efficiency at 100 W/m²



---

ADVANTAGES OF JINGYANG ETFE SOLAR PANELS:

1. _{Stronger box package for durability and heat dissipation.}
2. _{Japan ETFE film coating for corrosion resistance, higher temperature tolerance, and higher efficiency.}
3. _{Suitable for both indoor and outdoor use.}
4. _{Service life of more than 8-10 years.}
5. _{Very thin and durable with less weight.}
6. _{Ideal for motorhomes, camping, boats, marine, RVs, buses, and car roofs.}
7. _{High cost performance for home energy investment or outdoor usage.}
8. _{Waterproof (IP67), snowproof, and resistant to small hail.}
9. _{By-pass diodes pre-installed in the junction box for enhanced performance.}
10. _{Package includes a pair of 2.5MM² cables with connectors (approximately 900mm / 35.43 inches cable length).}
11. _{Quick installation with 6 drill holes on the back panel.}



---

2. ETFE 32-110 Solar Panel:

Material: Monocrystalline silicon

Max. Power (Pmax): 110W ± 3%

Max. Power Voltage (Vmp): 19.50V

Max. Power Current (Imp): 5.60A

Open-Circuit Voltage (Voc): 23.4V

Short-Circuit Current (Isc): 6.10A

Nominal Operating Cell Temp. (NOCT): -45 to 80℃ / -49°F to 176°F

Max. System Voltage: DC1000V

Max. Series Fuse: 15A

Solar Cell:

• 33pcs 166mm*90.5mm; 12BB Solar Cell or
• 36pcs 166mm*83.5mm; 12BB Solar Cell (randomly shipped)

Dimensions:

• 1050mm (L) * 535mm (W) * 2.5mm (H)
• 41.33 inches (L) * 21.06 inches (W) * 0.09 inches (H)


Package Dimension:**

• 1080mm * 570mm * 40mm

• 42.52 inches * 22.44 inches * 1.57 inches
• Package Weight: 1.95kg



Standard Test Conditions: AM=1.5, Irradiance=1000W/m², Temp.=25℃

Warranty: 1 Year

Lifetime: 8-10 Years

_{Additional Information: Minor reduction in efficiency under partial load conditions at 25°C: achieves 95% (+/-5%) of STC efficiency at 100 W/m²}



---

EDUCATIONAL INFORMATION:

Monocrystalline silicon solar panels, like the ETFE models described, are known for their high efficiency and longevity. They are made from a single crystal structure, offering higher efficiency rates compared to other types like polycrystalline or thin-film solar panels. Monocrystalline panels are ideal for situations where space is limited but high power output is required, such as residential rooftops or off-grid applications.

The power range of these panels, 90W and 110W respectively, indicates the maximum power output they can generate under standard test conditions. This power output is influenced by factors such as sunlight intensity, temperature, and shading. It's important for users to consider their energy needs and available space when selecting solar panels to ensure optimal performance and cost-effectiveness.

If you have any further questions or need assistance, please feel free to reach out. We're here to help!

Sunny greetings,

YOUR GLOBAL OASIS

YOUR POSSIBILITIES:

Camping and Motorhome/Van-Life:

1. A 200W panel can provide sufficient power to charge essential camping electronics such as smartphones, LED lights, portable fans, and small appliances like mini-fridges or coolers.
2. With a 400W panel, you can expand your power capacity, enabling the use of additional devices such as laptops, portable power stations, and even small TVs or sound systems for enhanced camping experiences.

Boats and Marine:

1. For boats, a 200W panel can power navigation equipment, radios, lighting systems, and small water pumps.
2. A 400W panel offers increased power capability, allowing for the operation of larger electronics like marine refrigerators, fish finders, and onboard entertainment systems.

IMPORTANT CONSIDERATIONS:

• Device Compatibility: Ensure that the devices you intend to power are compatible with the voltage and power output of your solar panel system.
• Simultaneous Usage: Consider the total power consumption of all devices that may be running simultaneously. This helps in determining the appropriate panel size and battery capacity to meet your energy needs efficiently.
• Battery Storage: Incorporating a suitable battery storage solution is essential for storing excess solar energy generated during the day for use during periods of low sunlight or at night.

"By carefully assessing your energy requirements and understanding the capabilities of solar panels, you can create sustainable and reliable power solutions tailored to your specific needs, whether for outdoor adventures, recreational vehicles, marine vessels, or other applications"



---

This overview highlights the versatility of solar panels in providing clean and renewable energy for a wide range of electronic devices, emphasizing the importance of proper planning and consideration for optimal performance and usability.
